Product description
Introduction
LAxLimit is an advanced look ahead, wideband linked-stereo limiter including ISP (inter sample peak) detection and oversampling.
As the successor to our widely popular LA xLimit IV, LA xLimit V offers enhanced control over transients and adaptive release curves.
Designed for today’s mixing and mastering demands, it delivers exceptional versatility across a broad range of limiting applications, with a strong focus on minimizing aliasing.
Overview
Generally
LA xLimit V is specifically engineered for mastering, digital editing, multimedia, and any audio application demanding top-tier limiting with exceptionally low aliasing.
Precision Compliance & Loudness Standards
To satisfy today's stringent broadcast, TV, and streaming requirements, LA xLimit V features True-Peak limiting (ISP) compliant with the ITU BS.1770-4 specification, alongside up to 64x oversampling.
Architecture
At the core of LA xLimit V are two independent brickwall/look-ahead limiters that can operate either in serial or parallel mode.
Brick-wall/look-ahead limiter
The operation of the limiter is primarily controlled by the drive, tone, attack and release controls.
Adaptive Attack
Automatically adjusts ratio of clipper/limiter levels based on internal transient detection. It minimizes typical side effects of brute force clipping such as unwanted distortion or crackling.
Adaptive Release
Adaptive Release recalculates the release curve for each sample. This minimizes typical aliasing during the limiting process.
Enhancer
Utilizing custom soft-clipping algorithms driven by adaptive compression, it intelligently boosts perceived volume and density without increasing peak levels. The Enhancer can be placed either before or after the limiter stage.
Dithering and noise shaping
The Dither module support various bit depths and noise profiles.
What’s New in Version 5:
Refreshed Interface: A modernized look and feel, complete with updated GUI layouts and customizable color schemes.
Full Serial and Parallel Functionality: Features a second parallel limiter for complete stereo control or a second serial limiter of extended limiting applications.
Enhanced Performance: Upgraded oversampling algorithms and significantly reduced plugin latency.
Adaptive Attack Control: Automatically adjusts ratio of clipper/limiter levels based on internal transient detection for improved transient handling.
Enhancer: Drives signal though a soft clipper/wave shaper for more volume.
Dithering and Noise Shaping: Dithering helps to preserve (perceived) detail and resolution by reducing quantize distortion.
Features
- state of the art low aliasing look ahead limiter design
- second limiter for dual-mono or serial applications
- freely adjustable limiter character
- adaptive attack control
- enhancer, pre/post limiter
- adjustable frequency sensitivity of detector signal
- freely adjustable adaptive release curves
- stereo link
- Mid-side processing mode
- DAW tempo based release times
- True peak limiting based on ITU BS1770.4
- RMS, EBU R128 and DIAL (Dialog loudness measurement) measurement modes
- DC blocker
- Dither and noise shaping
- side chain support
- up to 64x linear phase oversampling
- adjustable latency modes
- unity gain and delta monitor modes
- extensive monitor options
- comprehensive real-time level display including infinity mode
- input/side-chain/output and gain reduction meters with adjustable scales
- True peak metering
- support all sample rates
- parameter A/B
- parameter undo/redo
- preset management
- GUI themes
- GUI layouts (minimal, compact and large)
- GUI scaling
- low CPU usage
- Plugin menu: the plugin menu provides access to more plugin information, the manual, tool-tips control and more plugin options.
- Preset menu: the preset menu provides access to default, factory and user presets.
- Oversampling: sets oversampling up to x64.
- Dual limiter engine: selects either single or dual-mono limiter mode.
- Enhancer: reach loudness levels beyond normal limiting with highest possible clarity.
- Monitoring: flexible monitoring like left/right/mid/side channel from input/side-chain/output signal.
- Loudness information: this section shows loudness information (RMS/EBU/DIAL) of the limiting process.
- GUI scale: click and drag with the mouse to scale the GUI. For quick scaling, double-click.
Sound examples (*)
| Original | Processed | Settings | Loudness | |
|---|---|---|---|---|
| Drum Mix1 | dB 9 Drive/80% Enhance/Enhance pre-limiter | +5.7 LUFS | ||
| Master1 | dB 9 Drive/75% Enhance/Enhance pre-limiter | +7.1 LUFS |
(*) For an optimal listening experience, the loudness of original and processed sound samples is matched.
Important notes:
Before downloading and installing please check the system requirements!
Demo version versus Registered version:
In demo mode (without registering) the plugin mutes audio every 90 seconds for a short period. This could be circumvented by clicking on the "TBProAudio" logo within 90 seconds.
Activation:
After installation product is in demo mode and needs to be activated. Please follow the steps described in the manual or here.
Purchase:
Before any purchase please test the product, read and accept the terms listed here.
